Kenmore Stackable Washer and Dryer Not Draining?- Here’re the Quick Fixes!

Kenmore Stackable Washer and Dryer Not Draining?
( Disclaimer: As an Amazon Associate, we earn commissions from qualifying purchases at NO additional cost to the customer.)

One of the most well-known manufacturers of premium home washers continues to be Kenmore.

In the USA, a Kenmore washer or other appliance from this brand may be found in almost every third home.

A series of commercial Kenmore washers is also available; these washers are utilized by companies all over the world.

Besides excellent functionalities, there is not any such thing which is free of problems.

Some errors are also observed while running the washers which may be due to human negligence or systematic issues.

One of the issues that seems to appear is related to draining i.e Stackable washer and dryer is not draining.

There are several reasons to occur this issue such as faulty control board, damaged pump belt, clogged drain pump, broken door lock or lid switch assembly.

Let’s dive into detail.

Kenmore Stackable Washer and Dryer Not Draining?- Reasons

Various possible causes of drainage problem in Kenmore stackable washer and dryer are investigated below.

Washer/Dryer Control Board

Control Board is the integral part of the machine that is responsible for electric supply.

The drain pump may not be receiving power during the drain cycle if a washing machine’s control board is malfunctioning because nearly all of the washer’s electrical components are powered by the board.

Since control board is one of the major component, any fault in this board lead to cause different errors in washers.

The malfunctioning of components can lead to failure of drain in washer and dryer.

Hence, the control board must be fully functional for smooth operation.

Pump belt

A water pump belt can be seen on some vintage washing machines.

The component that enables the drum to rotate throughout the wash cycle is the belt, which is located between the motor and the drum pulley in the washing machine.

It is seen that the damaged pump belt fail to deliver the job effectively.

The water pump belt must not be damaged or worn out for the washer to drain.

A broken or worn-out pump belt may be the cause of the washer’s inability to drain.

Drain pump

During the spin cycle of a washing machine, the drain function removes water from the tub.

Water from the washer’s bottom is pumped into the drain pipe by the washer pump.

The tub can fill thanks to the washer’s drain tube, which loops to the machine’s top before going down to the drain.

The curve in the hose is where the water exits the drain.

Sometimes, small objects or articles of clothing can get caught in the drain pump.

A clogged pump or line may be the cause of the washer’s inability to drain.

Small socks and other clothing articles frequently find their way into the water drainage system and clog the line leading to the pump or the pump itself.

Door Lock Motor and Switch Assembly

The washing door is kept shut while in use by the door lock.

The washer can start working after the door is shut.

The door switch will stop the washer from working if the washer door is not fastened shut.

The washer won’t spin or start if the door lock is broken.

Therefore, the door lock motor and switch assembly must be thoroughly examined and must be capable of full potential in order to solve drainage problems.

Lid Switch Assembly

In order to keep the lid from opening during a wash cycle, washing machines contain lid locks that lock the lid into place.

The lid switch makes sure that the washing door is shut while it is spinning.

The washer won’t spin if the lid switch is damaged.

The lid switch is probably broken if the washer won’t spin but will still agitate.

When using the washing machine, this interlocking function acts as a safety measure to eliminate any potential risks.

The washer cannot spin when the lid is open thanks to the lid switch system.

The washer won’t drain if the assembly for the lid switch breaks.

Kenmore Stackable Washer and Dryer Not Draining? -Solutions

The possible solutions to get rid of drainage issues in washer and dryer are discussed below:

Control Board

Since control board is the important component, therefore, inspection of control board is mandatory for smooth drainage of washer and dryer as a first step.

For indications of burning or a component that has shorted out, one might examine the board.

After examining the wiring schematic for the appliance, one can also use a multimeter to check for incoming power to the drain pump.

When the washer is in the drain cycle and there is no voltage, the control board is probably broken and needs to be replaced.

Drain Pump

In order to pump wastewater from the washing machine, a drain pump needs to have enough suction.

They frequently stand close to the rear of the device.

It enables the flow of water through a little pipe that connects to the drainage system.

The term “drain hoses” refers to these tiny, flexible pipes.

In order to avoid drain pump error, remove the drain pump and look inside the pump for any obstructions to see if anything is preventing it from working.

If there are no blockages in the way of the drain pump but it still makes noise when draining, replace it.

Door Lock Motor and Switch Assembly

The next step is to investigate the door lock and switch assembly.

Both mechanical and electrical failures are possible with the door lock.

Hence, the door lock must be checked for damage.

Replace the door lock if it is damaged or if the latch is not working properly.

It is advisable to consult the wiring schematic for the washer.

A multimeter can be used to check each of the door lock switches for continuity to discover whether the door lock has electrically failed.

Replace the switch if any of the switches are not sustaining current.

Check/ Replace Lid Switch Assembly

The lid switch assembly must be checked if the drainage problem occurs in washer and dryer.

A multimeter is utilized to check each of the lid switches for continuity.

It is necessary in order to establish whether the lid switch assembly is flawed.

Replace the lid switch if continuity is not present.

Coin Trap

Coins, jewels, and small tokens can all find their way down the washer’s drain.

As a result, most washers contain “coin traps” that are built to collect them in order to prevent clogs from spreading further into the system.

The problem is that these coin traps themselves have the potential to jam up over time, which would prevent proper drainage.

A clogged coin trap could be the cause of the washer’s inability to drain.

There is a coin trap on this washer, which is located next to the water pump.

Any foreign objects that fall into the drain will be caught by this device.

In most cases, an access panel is used to gain entry to the coin trap.

It is usually simple to clear out and is made with the homeowner in mind.

Drain Hoses

Along with two distinct hoses for each cold and hot water delivery, the drain hose is often located on the washer’s back.

The machines hot and cold water supply lines bring in clean water, while the drain hose transports wastewater out of the device.

The drain hose should be checked if the washer won’t drain water.

Firstly, do inspection of drain hoses.

Then, check to make sure the hose did not kink behind the washer.

The next step is to remove the pump’s hose and inspect it for clogs as well.

All these steps will help to resolve drainage issue.
