Speed Queen Washer Error Code Ed44: The Inside Story!

Speed Queen Washer Error Code Ed44
( Disclaimer: As an Amazon Associate, we earn commissions from qualifying purchases at NO additional cost to the customer.)

For long-lasting, dependable performance and exceptional wash results, Speed Queen Washers are toughly built with premium materials.

The performance of Speed Queen top load washers is developed, tested, and constructed to last up to 25 years.

Speed Queen top load washers are built better and last longer since they are made with metal components and are extensively tested to assure reliable operation.

However, there are potential chances that the functionality of washers may disturb due to some error.

The chances of various errors including personal error, systematic error and random error are always present.

In speed queen washers, the supply of electricity must be free of errors.

One of the washer error that may exists is error Ed 44 that is Overcurrent Shunt Detection Circuit Fail Error.

Speed Queen Washer Error Code Ed44- Meaning

Ed 44: Overcurrent Shunt Detection Circuit Fail Error

The error Ed 44 may exists in Speed Queen Washers which represents the failure in shunt detection.

It is referred as “Overcurrent Shunt detection Circuit failure”.

An overcurrent is a condition which exists in an electrical circuit when the normal load current is exceeded.

A shunt is an electrical device that generates a low-resistance path for an electrical current.

This enables the current to flow to an alternative point in the circuit.

This error indicates the absence of detection of current in circuit which disrupt the normal functions of Speed Queen Washers.

Sources of Speed Queen Washer Error Code Ed44

Hardware failure

One of the major reasons of this error is the failure of hardware.

It is necessary that all components must properly connected and should function smoothly.

In case of error ed 44, the hardware components may fail to work effectively.

It is necessary that the hardware must be fit since it is the integral component of the washers.

Components of hardware can be harmed by an unregulated power source of any kind.

Incorporated into this are electrical surges caused by lightning or the main power line.

Hardware failure may also be caused by ESD and inadequate equipment grounding.

Personal Errors

In any working machine, there are always chances that personal and systematic error may occur.

It is possible that due to some human negligence, the error appears.

It is an essential consideration that a person must aware to handle the equipment with great care.

Furthermore, the equipment must be inspected firstly in order to check if any fault occur in washers.

In washers, if ed44 arises it means that excessive current results in circuit failure.

Thus, interrupts the power supply.

Due to this, washers stop to work and hence result in waste of time.

Therefore, one must look firstly these things before start of working of washer for uninterrupted power supply.

Drive Board

Drive board is used to control the speed and direction of current.

They are typically employed to control other elements, such as other components and some other devices in the circuit, or to regulate the amount of current that flows through a circuit.

In case of Ed44 error, since the alternate current paths detection cannot be distinguished due to excessive supply of current, therefore, there are potential chances that drive board is not working properly.

The drive board become unable to work properly in such a case.

Hence, the drive board factor cannot be neglected.

Motor Control

Motor control refers to manual or automatic methods for starting, stopping, controlling speed, reversing, and protecting a motor.

These controls are achieved using a variety of circuits, connections and sensors.

It is understandable that it is one of the vital component that needs to be considered in case of error ed 44.

Since it is known that the faster the current switches direction, the faster the motor spins.

In case of motor control failure, the overcurrent shunt detection may not work effectively and hence results in circuit failure.

Miscellaneous Issue

In inspection of causes of error ed 44, in addition to all above mentioned factors, it is quite possible that overcurrent shunt detection circuit failure occurs due to any other problems in washers of Speed Queen machine.

As washing machine have various components that are interconnected, it is necessary to check if all components are working normally.

With circuit, if any associated part starts trouble, it may interrupt the working of shunt detection.

Furthermore, any of the component failure may result in failure to detect overcurrent shunt circuit.

Therefore, one must handle the machine with great care.

Speed Queen Washer Error Code Ed44- Solutions


The very first step is to tackle error Ed 44 is to restart the washing machine.

There are opportunities that the error appears without any specific reason.

Firstly, do external inspection and initiate it with restart of appliances.

For restart, unplug the main switch and give rest the dryer for at least five minutes.

Make sure that all wires are connected properly at right place.

Then after few minutes, switch on the washer.

The washer must work smoothly, and the issue must be resolved if it is the problem.

However, if the error Ed 44 continues to appear, then one must look in for other reasons.

Motor Control board

The pace at which the washer spins is controlled by the motor control board.

The washer won’t spin or agitate if there is a problem with the motor control board.

Due to this, the ed 44 may occur.

Therefore, the motor control board must be checked properly and make ensure if it is working normally.

In case of failure in motor control board, it is advised that some expertise guide must be taken.

However, it is preferable that the motor control board must be replaced to avoid any future hazards.

Wire Harness Connections

It is an essential and foremost step to make sure that all connections are working properly.

Check wire harness connection between motor, user control and output board.

One must make sure that wire harness connections among motor switch, user control, and output board are secured firmly.

There are chances that these may become loose due to which the error arises.

It is quite possible these wire harness connections may get damaged.

In this case, it needs to be replaced.

After replacement, make sure that all connections are secured tightly and there must not be any loose connection.

Hence, it will eliminate the issue.

Drive board

Drive boards must be inspected with extensive care in order to make sure that the washers are working efficiently within normal current range.

In case of error ed 44, the factor of drive board issue cannot be overlooked.

In case of failure in drive board, one must call a technician to get help.

With the expertise help, the issue of drive board is largely resolved.

However, if the issue with the drive board persists, it is necessary to replace it since it is the only option.

With the replacement of drive board, all the components work normally and hence eliminate the error Ed 44.

Need of Expertise

Since it is mentioned that in any working of equipment, the various errors are always present which in turn lead to other errors.

Human expertise is something needed and required whenever dealt with any equipment.

Therefore, to avoid any error in Speed queen washers, one must be trained or get knowledge on how to use the machine effectively.

Furthermore, the machines must be examined thoroughly in order to avoid any instrumental error.

With the expertise help and excellent calibration of the instrument, the various errors can be eliminated.
