Whirlpool Refrigerator Makes Clicking Noise: 6 Main Reasons & 5 Solutions!

Whirlpool Refrigerator Clicking Noise
( Disclaimer: As an Amazon Associate, we earn commissions from qualifying purchases at NO additional cost to the customer.)

Recently noticed your whirlpool refrigerator clicking noise?

Do not panic! We have answers.

The first information you need to know is that a compressor is located behind any refrigerator.

It’s responsible for compressing the refrigerant gas while initiating the cooling operation.

If it draws excessive energy because of the overload condition then it will get overheat and you will notice a clicking sound whenever it shuts down to safeguard itself.

You might notice some other clicking noise as it kicks on immediately once it absorbs the heat and cools down. That can be the main reason.

But there are other causes as well, and we know you are trying to figure out those answers.

We have outlined some information in this article to make your life a bit easier.

Scroll down to understand the reasons and solutions to this issue.

Main Causes For Whirlpool Refrigerator Clicking Noise

There are specific reasons that might be responsible for your Whirlpool refrigerator clicking noise.

We have discussed some of them below:

Dirt in Condenser Coils

Filthy condenser coils, placed beneath or behind your refrigerator, are a typical source of compressor overloading.

The refrigerant travels through the condenser tube to exchange heat with surrounding air. This makes the air warmer and refrigerant cooler.

These coils cannot exchange heat with ambient air smoothly if it is coated with dirt, lint, grease, or similar junk, so the equipment has to operate extremely hard to chill the refrigerator.

You may have noticed that your refrigerator is chilly, but not quite as chilly as it must be.

Faulty Start Relay

The compressor will not operate consistently when your refrigerator has completely stopped chilling, plus you notice a clicking noise between 2 to 5 minutes.

The start relay activates the compressor, allowing it to initiate the cooling cycle by pressurizing the refrigerant gas within the machine.

This little gadget is usually found in the same chamber as the compressor, connecting to the edge.

The start relay may click, indicating its attempt to perform its duty, yet the compressor may not turn on when it is malfunctioning.

It will repeatedly attempt in a brief period but will fail.

Water Faucet

The water faucet can beep or click when it attempts to load the ice maker.

If your refrigerator features an ice maker and is not hooked to a water source, clicking noise might come from this.

Regular Cooling Function

If the twin evaporator valve starts modulating the cooling function, you might notice a continuous clicking sound.

As the device changes from conditioning one chamber to conditioning another, you might notice quick repetitive clicking noises.

This is a common noise. There is nothing to worry about.

Imbalanced Surface

It is essential to keep your refrigerator balanced.

A correctly positioned refrigerator can improve the functioning of any refrigerator.

Try and ensure the ground beneath your refrigerator is flat. Shims might be required to balance the refrigerator when the surface is not flat.

For precise balancing requirements regarding the refrigerator, read your user’s guide or setup instructions.

Condenser Fan

Examine the condition of the condenser fan.

The refrigerant within the coils is cooled by it.

Whenever the fan does not switch on while the compressor is working, it will heat up.

Therefore, you end up hearing the clicking on and off noise by the compressor.

Whirlpool Refrigerator Clicking Noise: Solutions

There are some easy solutions when you encounter Whirlpool refrigerator clicking noise.

You have complied them below; keep reading:

Clean the Condenser Coil

Suppose you find that then your condenser coil is dirty; clean it.

You must clean the condenser coil at least yearly.

To avoid being shocked, disconnect the refrigerator from power and gently sanitize the coils.

A lot of plumbing shops provide specifically made brushes to make this work much easier.

Reconnect your refrigerator after the coils have been cleaned.

Change the Start Relay if Needed

Deactivate your refrigerator’s electricity and remove the start relay from its adapter from the compressor’s edge to verify that it is the source of the issue.

Give the start relay a good shakin’.

If anything seems rattling, then it would be defective and has to be changed.

To ascertain if a relay has stability, it might be necessary to check it using a multimeter.

Once it is confirmed to be defective, just simply replace it with a new one.

Be careful to disconnect the refrigerator before replacing it.

Take off the cardboard top from the bulk of the refrigerator modules’ rear ends.

Then pull out the plastic top from the compressor’s edge.

It is fastened via a silver hook.

Now it should be clear to access the relay, and you can remove it right away.

Try to be aware of the relay’s cabling and location.

On the compressor, there are just three connections.

If you visit an appliance parts store, you can purchase a replacement and provide the manufacturer’s name and product code.

The replacement one connects to the exact port from which the previous one was uninstalled.

Reconnect your refrigerator, and your refrigerator should resume its regular operation.

You might like this start relay to sort things out in your whirlpool refrigerator!

This refrigerator compressor start device relay and overload assembly is made of high-quality material and well tested too.

It comes with higher efficiency, durability and the best quality for a longer service life.

This compressor relay is very easy to snap into place as you don’t need any tools to fix it.

It is the perfect match and good choice for direct replacement of original parts.

Funmit 2319792 TSD2 Refrigerator Compressor Start Relay Device (Upgraded Version) Replacement for Whirlpool Replaces 1195945 AP6007299 PS11740412 EAP11740412 2255198

Attach Water Supply

If the clicking noise occurs due to the ice maker not being connected to a water supply, simply connect to a water supply.

Once done, the sound should not be get repeated.

If the sound still exists, make sure to check the other parts.

Replace Compressor

If the refrigerator’s compressor is damaged, you might have to hire an expert to determine if it should be repaired or you may go for this compressor to replace the faulty with a new one.

This is an EMBRACO Refrigeration Compressor that can be used as a replacement for your whirlpool refrigerator that has specifications like 1/3 H.P. and 115 Volts, and draws 5.80 Amps.  It comes with size of 6.5″ x 4″.

Suppose your refrigerator is a newer model.

In that case, there may be alternative explanations for the compressor getting too hot and making a noise that is simple to evaluate and fix.

Contact a Pro

If neither of the suggestions mentioned above succeeds, an expert refrigerator technician is likely required.

It might be prudent to replace the compressor from a contemporary refrigerator that is still in good working condition.

If you are considering an aged machine, a modern sustainable refrigerator can be a wiser investment.

Why is your Whirlpool Refrigerator Clicking and Not Cooling?

If the contents in your refrigerator are starting to go bad, you may observe that the current heat-up of the machine is complemented with a clicking sound.

The sad thing is that the refrigerator requires emergency maintenance, but the fortunate side is that anyone can simply identify the problem.

There are just a few causes that can generate simultaneous clicking plus a halt or reduction in freezing.

You might be capable of fixing it yourself instead of paying an expert and wasting bucks.

This might happen due to a bad compressor or bad relay.

All the reasons that are mentioned above can be responsible for this issue.

Both are interlinked.

So, before rushing to an expert or spending extra money, check if any of these reasons can be applied or not.

If you can connect the dots, you might easily solve the issue following our suggestions.

When you cannot, consult an expert.

Final Words

We hope this article helped to find the possible solutions for your Whirlpool refrigerator clicking noise.

If you want to research and find out more, check Whirlpool’s website.

They might be able to answer your questions in detail.

Or, you can call customer service for a quick conversation.
